Product Description:
Frequency Range | 20-6000MHz/700-2600MHz |
Frequency: | CDMA/GSM/3G Cellphone |
Jammer Type | Waterproof Outdoor Signal Jammer |
Channel Numbe | 9 |
Each Bands Power | 50W |
Total Output Power | 450W |
Jamming Range | 25-300m |
Application | Military Units, Prison, Police, Bomb Disposal |
Product Description:
It is designed for Protect military and country leaders VIP team, EOD, police investigation and arrest prisons, government buildings, wireless remote bomb and some occasions for a temporary protection to respond to some emergencies.
Application fields
-Bomb disposal and military automobile allocation;
-Field operations;
-Special troops;
-VIP protection;
-Bandit suppression.
The powerful jammer has a wide affected frequency ranges to include CDMA/GSM, DCS/PCS, 3G, 4G LTE, 4G Wimax and Wifi. It also has a jamming range up to 1000m, depending on the signal strength in the given area. Within the range, just turn on the jammer, all wireless connection to 2G, 3G, 4G or Wifi network will be disabled at the same time. Also, the jammer is a selectable unit. In other word, user can choose to allow operation of one or a few of frequency bands. Adjustment of ON or OFF any of the single bands will not cause any disruption to the operation of others.
Specification:
CH1 | -4G LTE:(USA:725-770MHz) or (Europe:790-826MHz) |
CH2 | -4G Wimax (US.2345-2400MHz or (EU.2620-2690MHz) |
CH3 | -800-850MHz/Walky-Talky(UHF700/800), TETRA |
CH4 | -850-895MHz/Cellular CDMA/TDMA,alky-Talky ( UHF800/900 ) |
CH5 | -925-960MHz/Cellular GSM900 |
CH6 | -1520-1580MHz/GPS & Satellite; Thuraya; Iridium; Odyssey; GlobalStar; Inmarsat; Aces; Elipso |
CH7 | -1805-1990MHz/Cellular HGSM1800/ DCS??Cellular GSM1900/ PCS (+ PHS ) |
CH8 | -2110-2170MHz/Cellular UMTS / WCDMA ( 3G ) |
CH9 | -2400-2500MHz/WLAN & Bluetooth & Wifi |
Total RF Power | 700 Watt |
Antenna Type: | High Gain Omnidirectional Antennas |
Power Supply Source: | Additional AC Generator ( 5000W) |
Jammer Module Number | 9 |
Total Power Consumption ( +28VDC ): | Max 7000VA |
Total System Weight: Approx. | 50kg |
Operating Humidity: | Up to 80% |
Accessories:
- Power cable
- Antennas
- User manual
Terms and conditions:
Delivery Time Schedule | Delivery time is 3-4 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
Payment Terms | 40% advance, 40% after one month,20% before shipping. |
Terms of Delivery | FOB HONGKONG/ USA. |
Warranty | 36 months. |
Software Updates | Free software updates will be provided for a period of 36 months. |
Extended Warranty | After 4th Year : 5% of total for each years. |
