Product description :
| Frequency Range | 20-6000MHz/700-2600MHz |
| Frequency: | CDMA/GSM/3G Cellphone |
| Jammer Type | Vehicle Bomb Jammer |
| Channel Number | 13 |
| Each Bands Power | 50W |
| Total Output Power | 600W |
| Jamming Range | 2-90m |
| Application | Military Units, Prison, Police, Bomb Disposal |
Full Frequency Vehicle Jammer 20 - 3000 MHz Remote Control Switches
Specification
Affected Frequency Ranges: (13bands option)
| Output Interface | Output Frequency | RF Output watt |
| CH1 | 20-80MHz | 100W |
| CH2 | 80-200MHz | 100W |
| CH3 | 200-500MHz | 100W |
| CH4 | 500-1000MHz | 50W |
| CH5 | 1000-1500MHz | 50W |
| CH6 | 1500-2000MHz | 50W |
| CH7 | 2000-2500MHz | 50W |
| CH8 | 2500-3000MHz | 50W |
| CH9 | 870-880MHz | 50W |
| CH10 | 935-960MHz | 50W |
| CH11 | 1805-1920MHz | 50W |
| CH12 | 935-960MHz | 50W |
| CH13 | 2400-2500MHz | 50W |
| Total output power: | 600~1300W | |
| Power supply | 50 to 60Hz, 100 to 240V AC | |
| Shielding area | up to 500m, the jamming radius still depends on the strength signal in given area | |
| Jammer Module Number | 13 | |
| Cooling System | Systematic Smart Cooling System | |
| System Protection | VSWR, Over-voltage, Over-current | |
| With AC adapter | (AC100-240V-DC27V), | |
| Remote Control (Option) | Each band can work independently | |
| Antenna Type | all the TX frequency covered down link only | |
| Number of Antennas | 13 | |
| Vehicle Platform(Option) | Off-road four-wheel drive car | |
| Power consumption: | 800W | |
| Weight: | About 45 kg (with omnidirectional antenna.) | |
| Size (length × wind × high) | 625×500×700 mm | |
OTHER: Customize frequency
Accessories
- High Power Cell Phone Signal Jammer
- Antennas
- Power cable
Other details:
Most of us know that in important places like prisons, military meeting and museums, actions have always been taken to prevent the message from being given out. What kind of device can install in these places to reach the purpose, the Rackmount High Power Cell Phone Signal Jammer must be the one which is most suitable.
A big merit of this rockmount high power cell phone signal jammer is that each band can adjust RF power output level or turn off without influencing the other bands' operation.
The original antenna is external double channel directional panel antennas and you can select antennas to provide more flexibility regarding jamming coverage.
The jamming coverage of this jammer is so strong that the jamming range could reach 500m, but the jamming range is also determined by the strength of signal in given area.
Seen from its function this one jamming device is really a good one. If you are looking for one, come here! High quality and reasonable price is our promise.
Monitor software function: (Option)
Remote control switches of each machine.
Remote viewing each machine working state.
The power output of each machine remote adjustment.
Remote viewing offline log of each machine.
Mail receiving each machine working state.
The system can set permissions to log on.
Terms and conditions:
| Delivery Time Schedule | Delivery time is 1 or 2 months, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms | 40% advance, 40% after one month,20% before shipping. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year : 5% of total for each years. |
R&D Group in USA
We have strong and excellent R&D group in USA, who dedicated to the research and development of our new products.We are consumer-oriented and do our best to offer satisfying products to customers.
Manufacturer in CHINA
A full line of products - We have a full line of cellular jamming products from low-cost portable units to high-spec industrial units.
We are the specialists in cell phone Jammers and GPS Jammer, WIFI Jammer, 3G Jammer, 4G Jammer, Lojack Jammer, UHF/VHF Jammer, RF Jammer, Audio Jammer,Wireless Video Jammer and signal Repeater/Amplifier/Booster etc.We offer unparalleled professional service and advice for our personal and commercial products. 10+ years of industry experience makes us the specialists you can trust. We pioneered all kind of jammers online sales, and offer the best cellular jamming prices worldwide - guaranteed. We are a developer, manufacturer and reseller of cell phone jamming devices and signal Repeater devices. products include GSM Jammer, CDMA jammer, DCS/PCS Jammer, GPS Jammer, WIFI Jammer, 3G Jammer, Audio Jammer, Wireless Video Jammer, Dual Band Repeater,Tri Band Repeater etc.
Our Jammer type have Portable Jammers, Desktop Jammer, Prison Jamme, Vehicular jammer, Bomb Jammer, IED Jammer and RF Jammer.
