Product Description
| Frequency Range | 20-6000MHz/700-2600MHz |
| Frequency: | CDMA/GSM/3G Cellphone |
| Jammer Type | Portable Jammer |
| Channel Number | 10 |
| Each Bands Power | 50W |
| Total Output Power | 500W |
| Jamming Range | 2-90m |
| Application | Military Units, Prison, Police, Bomb Disposal |
Key Specifications/ Special Features:
Product description:
Military / Police / Government / Convoy Portable RCIED Jammer 12 bands
Applications :
Anti-terror units, Bomb squads, VIP protection, Convoys protection, Military forces, SWAT teams, Police forces, Anti-drug units, Riot-control units, Embassies protection, Roadblock protection, Checkpoint protection
It is designed for Protect military and country leaders VIP team,EOD,police investigation and arrestprisons,government buildings, wireless remote bomb and some occasions for a temporary protection to respond to some emergencies.
Affected Frequency Ranges:(14 bands )
| Output Interface | Output Frequency | Average out-putting power |
| CH1 | 137-175MHZ | 50W |
| CH2 | 300-350MHZ | 50W |
| CH3 | 400-480MHZ | 50W |
| CH4 | 800-920MHZ | 50W |
| CH5 | 925-960MHZ | 50W |
| CH6 | 1805-1800MHZ | 50W |
| CH7 | 1920-1990MHZ | 50W |
| CH8 | 720-785(US)/ 790-826 (EU) 4G LTE | 50W |
| CH9 | 3G 2100-2170 MHZ | 50W |
| CH10 |
4G 2300-2400 MHZ (US) or 2570-2690 MHZ (EU) |
50W |
| CH11 | GPS 1520-1580 | 50W |
| CH12 | WIFI 2.4G 2400-2500 MHZ | 50W |
| CH13 | 5G LTE 2600 2620-2690 MHz | 50W |
| CH14 | 5G LTE 3500 3500-3600 MHz | 50W |
Total RF output power: 600W (Adjustable output power for each band)
Jamming Range: 100-1000 meters@-75dBm
Power supply: AC adapter (AC220V-DC27V or 24V/ 40-50 Amp)
Adjustable Output Power each Band, Stand-alone modular design and individual power control.
Temperature over protection.
Working status indicator for each band modular.
Dimension: 69cm(L)×69cm(W)×39cm(D)
Weight: 45 Kg (approximately) just main unit not included antenna & all accessories
Operating temperature: -20ºC ~ +60&
Advantages and Features
• Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.
• Heat sink designing combing with the fans to make system in a cooling status.
• Special technology to prevent interference between each frequency band.
• Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
• Frequency bands and output power selectable.
• Each frequency band controlled by independent RF ON/OFF switches.
• Power of each frequency band can be adjustable independently.
• Circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection.
• Antenna type options, directional or Omni-directional antennas option.
• Easy operation and installation.
• Keep for upgrade module installation.
• Working 24 hours/365days continuously.
Jammer is available in various models as per the frequency and output power. However these jammers can be customized as per the user requirements.
Portable case RCIED Jammer is a wide-band portable jamming system, designed for the protection of VIP's and groups of people from radio controlled improvised explosion by disabling the radio exploder control lines in dangerous areas and for the prevention of leakage of information through intercepting units during confidential talks.
Briefcase Jammer transmits RF interference and creates a "Radio Frequency Protected Zone" around the object that prevents remote controlled bomb activation by various RF means in its vicinity with a sufficient jamming safety radius, in order to save lives and prevent serious injuries. Case Jammers are also deployed to guard forces in the field, Dignitaries and VIP's, checkpoint and border crossings, roadblocks, Embassies, Police and Government offices etc.
Case Jammer is available in various models as per the frequency and output power. However these jammers can be customized as per the user requirements
Monitor software function: (Option)
· Remote control switches of each machine.
· Remote viewing each machine working state.
· The power output of each machine remote adjustment.
· Remote viewing offline log of each machine.
· Mail receiving each machine working state.
· The system can set permissions to log on.
Technique characteristics
· Taking use of super-high frequency with high effective power.
· Effective output power (channel power) and bigger interfere radius.
· Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
· Imported elements: Slow start up design of circuit. These elements can maintain the stable operation condition with high integration.
Terms and conditions:
| Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms | 40% advance, 40% after one month,20% before shipping. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year : 5% of total for each years. |
Important Notes for Jamming Distance: The jamming distances we mentioned on website are for customer's reference only. The actual jamming distance will be varied depending on the signal strength and the use location and if full charges, etc.
Important Notes for Portable Jammers with No Cooling Fan: Do not use the jammer when it is charging, or it will burn the jammer as it has no built-in fan. If because of this factor due to the broken of the jammer, the customer will lose the authority of free repairation .
