Basic Info.
| Frequency Range | 20-6000MHz/700-2600MHz |
| Frequency: | CDMA/GSM/3G Cellphone |
| Jammer Type | Portable Jammer |
| Channel Number | 3 |
| Each Bands Power | 80W |
| Total Output Power | 240W |
| Jamming Range | 2-90m |
| Application | Military Units, Prison, Police, Bomb Disposal |
Product Description
High quality jammers widely use in Militar y Units, Prison, Polic e, Bomb Disposal and Security Services.
Protect militar y and VIP team from the road-side remote improvised explosive device (RCIED) attack detonated by the terrorists. Moreover, It can prevent terrorists using GPS location to track the vehicles efficiently.
Used for EOD. Before EOD, wireless telecommunication signals surrounding the bomb must be blocked effectively to prevent the terrorists detonating the the bomb through the wireless remote control devices and avoid the huge casualties.
It can be applied that the common used telecommunication frequency will be blocked when the Polic e arrest the criminals in order to prevent the criminals gang or Polic e insider leaking the confidence through the wireless equipments ,so that the arrest collapsed. It also make the criminals not be able to remotely control the bomb in the key entrance of the building so that Polic e can quickly access to the building and round up the criminals to avoid the casualties.
Protecting the boarder and arm y patrol from the attack of road- side bomb RCIED denotated by the terrorists.
It can be used to prevent terrorists remotely controlling the bomb bursting points in militar y protection zone,government buildings and some other important places. It can also make the criminals hidden in the militar y protection zone not communicate with the outside gang to leak the confidence.
Specification
Affected Frequency Ranges:
|
CH1-CDMA 800: 850 to 894MHz |
|
CH2-GSM 900: 925 to 960MHz |
|
CH3-GSM 1800: 1805 to 1880MHz (DCS) |
|
CH4-GSM 1900: 1920 to 1990MHz (PCS) |
|
CH5-3G: 2110 to 2170MHz |
|
CH6-4G LTE: (USA:725-770MHz) or (Europe:790-826MHz) |
|
CH7-4G Wimax: (USA:2345-2400MHz) or (Europe:2620-2690MHz) |
|
CH-5G:3400-3600MHz/3600-3800MHz |
|
CH8-WiFi 2.4G: 2400-2500MHz |
|
CH9-WiFi 5.8G:5680-5900MHz |
|
CH10-GPSL1: 1570-1580MHz |
Other: Option Customize frequency
| CH -VHF: 136-174MHz |
| CH -UHF: 400-470MHz |
| CH - Lojack : 167-173 Mhz |
- Total output power: 600-1200 watt
- Jamming range: 100-1000 M , the jamming radius still depends on the strength signal in given area
- External double channel directional panel antennas all the TX frequency covered down link only
- Power supply: 50 to 60Hz, 100 to 240V AC
- With AC adapter (AC100-240V-DC27V),
- Dimension: 420×480×130 mm
Accessories
- High Power Cell Phone Signal Jammer
- Antennas
- Power cable
Romote Control Function: (Option)
- Remote control switches of each machine.
- Remote viewing each machine working state.
- Adjustment machine of each output power.
- Remote viewing offline log of each machine.
Monitor software function: (Option)
- Remote control switches of each machine.
- Remote viewing each machine working state.
- The power output of each machine remote adjustment.
- Remote viewing offline log of each machine.
- Mail receiving each machine working state.
- The system can set permissions to log on.
