20 - 3600MHz Portable Military Vehicle Bomb Jammer DDS High Power Cell Phone SIgnal Jammer
Product description :
DZ-WT700157 is High Power DDS Convoy Jamming System, implementing the most effective and reliable RF jamming technology and equipped with a fully-integrated broadband jamming system.
DZ-WT700157 - Fully portable multi-band DDS Jamming system, is designed with a ruggedized trolley type case, highly mobility. This device is configured with 6 different jamming modules, the jamming frequency can be more than 20Bands. Six jamming frequency modules can be up to 600 watt output power maximum.
The DZ-WT700157 is very easy to be installed and operated. The device can be powered by AC mains or a suitable DC power source. The general design of the system meets military requirements and international quality standards.
Features:
1,Field programmability for rapid adjustment frequency and output power.
2,Fully modular compact design with extremely high efficient cooling system provide very good system stability even in hard climatic conditions. Also easy for maintenance, repair and upgrade.
3,Jam up to six different jamming modules simultaneously, and cover up to 20 different frequency bands. Each module with LCD display to show its working frequency ,output power and etc.
4,Fully portable trolley-type case. Easy to be carried.
5,Supplied by AC mains or DC power source.Backup battery system or generator system can be optional.
6,The jamming system with an active smart cooling system in a continuously cycle working.
7,Based on our general design, we can further customize our systems to be client-specified scenarios both for military and civil applications in order to provide the best individual solution.
8,Bomb Detonating and confidence leaking, resulting from Road-side Remote Control Improvised Explosive Device (RCIED) have been tremendous challenge in many parts of the world.
Technical Specifications
| Type | Vehicle Bomb Jammer |
| Frequency Range | 20-3600MHz |
| Total RF Power | 260-360Watt, Max: 550Watt |
| Jamming Radius | 50-800M, the jamming radius still depends on the strength signal in given area |
| Jammer Module Number | 6 |
| Channel Frequency Number | 15Bands, Max: 24Bands |
| Cooling System | Systematic Smart Cooling System |
| System Protection | VSWR, Over-voltage, Over-current, |
| Jamming Source | Digital Signal Source Synthesize Technology Adjust Frequency and Output Watt |
| Remote Control | Full System Operation Control With Battery Led display |
| Antenna Type | High Gain Omnidirectional Antennas |
| Number of Antennas | 6 |
| External Battery | 35AH/24-28VDC |
| Jammer Module | Each Jammer module with antenna can be used as a single jammer. All modules are controlled separately. |
| Jammer Size | 63×49.2×35.2cm |
| Jamming System Weight | Approx.36kg |
| Operating Temperature | -35°C ~ +80°C |
| Operating Humidity | Up to 80% |
| HS Code | 8543709200 |
| Packing | Box |
Applicable Area:
• Special security and confidential occasions (confidential office, negotiation room, mobile vehicles, mobile political and business dignitaries guarding the scene;
• All kinds of military sites and other prohibited places to use mobile phones.
Terms and conditions:
| Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms | 40% advance, 40% after one month,20% before shipping. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year : 5% of total for each years. |
