| Frequency Range | 20-6000MHz/700-2600MHz |
| Frequency: | CDMA/GSM/3G Cellphone |
| Jammer Type | Waterproof Outdoor Signal Jammer |
| Channel Number | 4 |
| Each Bands Power | 10W |
| Total Output Power | 40W |
| Jamming Range | 25-300m |
| Application | Military Units, Prison, Police, Bomb Disposal |
4 bands ,total 60w police jammer ,Mobile Phone signal Jammer,for prison ,school
Description:
Each band power 0-15W adjustable, total 75W high power, block range up to 100 meters.
Nice out looking, can be upgrade into remote monitoring type operate through internet.
Taking use of technology of interference superhigh frequency. High effective channel power with rater big semidiameter of interception
Effectively making subsections, just interfering downlink and causing no interception of base station.
Specifications:
|
Frequency |
Average out-putting power |
Channel out-putting power |
|
CDMA 851-894MHz |
41．8dBm |
17．8dBm/30KHz(min) |
|
GSM 925-960MHz |
41．8dBm |
15．4 dBm/30KHz(min) |
|
DCS 1805-1880Hz(or PCS 1920-1990MHz) |
41．8dBm |
9dBm/30KHz(min) |
|
3G 2010-2170MHz |
41．8dBm |
5dBm/30KHz(min) |
|
Power:AC220V-DC27V Antenna: 5 pcs directional penal antennas Jamming Range(Radius) 20-100m(depend on site BTS signal intensity and environment conditions) |
||
|
Net Weight:15Kg Dimension: (L*W*H) 56*33*27cm Humidity: 30%-95% Running temperature: -40 to +55 Celsius Degree Working Hours:24 hours. |
||
Competitive Advantage:
1. with good cooling system, can operate for long time.
2 Control: turn on/off and adjust output power by hand.
3. High effective channel power with rater big semi-diameter of interception.
4. Effectively making subsections, just interfering downlink and causing no interception of base station.
Applications:
1. Conference room, auditoriums, law court, library, exam room, school, cinema, theater, museum, hospital etc.
2. Places where using mobile phones is prohibited such as Service Station, Security Services, Military Units, Border Patrol and Drug Enforcement, Customs, etc.
