Product description
Frequency Range | 20-6000MHz/700-2600MHz |
Frequency: | CDMA/GSM/3G Cellphone |
Jammer Type | BackPack Jammer |
Channel Number | 4 |
Each Bands Power | 50W |
Total Output Power | 200W |
Jamming Range | 2-90m |
Application | Military Units, Prison, Police, Bomb Disposal |
Key Specifications/ Special Features:
Product Description:
The High Power IED Jammer shall have the following feature. . Portability.
It shall be lightweight, man portable and comfort to use. . Safety of Usage. It shall be safe for use. . Simplicity. It shall be simple to set-up and easy to use. Robustness.
It shall be strong and robust to withstand crush, shock and vibration. Transportability. It shall be easily transportable by hand, Remote Explosive Ordnance Disposal
Vehicle (REODV) or on any EOD transport vehicle. Maintenance. It shall be simple to maintain during storage and use. Protection. It shall be protected from Radio Frequency and Electromagnetic interference. Reliability. All components shall be highly dependable to perform its required functions when used in any environment throughout its shelf life. Environment. It shall be fully tropicalization and not easily affected by the ingress of moisture or dust.
Advantages and Features:
• Aluminum-alloy casing with high protection has high resistance to dust, water and corroding.
• Heat sink designing combing with the fans to make system in a cooling status.
• Special technology to prevent interference between each frequency band.
• Only interfere downlink frequency of mobile system, without disturb normally working of Base Stations.
• Frequency bands and output power selectable.
• Each frequency band controlled by independent RF ON/OFF switches.
• Power of each frequency band can be adjustable independently.
• Circuit protection to ensure system will not burn out in case of antenna short circuiting or disconnection.
• Antenna type options, directional or Omni-directional antennas option.
• Easy operation and installation.
• Keep for upgrade module installation.
• Working 24 hours/365days continuously.
Specification
Affected Frequency Ranges: (10bands option)
Output InterfaceOutput FrequencyOutput power
Output Interface | Output Frequency | Output power |
CH1 | -GS900:925-960MHz | 50w |
CH2 | -4G LTE: 758-826MHz | 50w |
CH3 | -GPS L2-L5:1100-1300MHz | 50w |
CH4 | -WIFI2.4G: 2400-2500MHz | 50w |
- Total RF Power300W
- Power supplyAC220V
- Shielding area300m according to signal density of mobile network
- Jammer Module Number6
- Power consumption1000W
- Weight25.00 Kg
- Size (length x wind x high)320×380×230 mm
- Humidity30%-95%
- Running Temperature-20 to +55 Celsius Degree
- Battery Working Time (Option)2 or 3 hours
Accessories
- High Power Cell Phone Signal Jammer
- Antennas
- Power cable
Products Application Fields
High quality jammers widely use in Military Units, Prison, Police, Bomb Disposal and Security Services.
It can also be used in places like Prison, Gas Stations, Guard, Schools, Churches, Invigilate Meeting Room, Library, Hospitals, Theater, Class Room and other important places and situations.
Shipping Information
FOB Port | Shenzhen | ||||
---|---|---|---|---|---|
Lead Time | 15–20 days | ||||
Weight Per Unit | 15.0 Kilograms | ||||
Dimensions Per Unit | 35.0 x 30.0 x 28.0 Centimeters |
Units per Export Carton | 1.0 | ||||
---|---|---|---|---|---|
Export Carton Dimensions | 35 x 30 x 15 Centimeters | ||||
Export Carton Weight | 20 Kilograms |
